ED50/ED100/ED250 09-2021DL4617-003
dormakaba ED50/ED100/ED250 OHC Header
Setup and Troubleshooting Instructions
Chapter 14
. Customer supplied doors - pair door installation
 Pair door installation
Fig. 14.1.1 Pair door inswing example; ready for door installation
1 Overhead arm
rotated to 70
degrees or greater
2 Floor pivot
NOTICE
Door, jambs, and finger guards by customer.
Door installation:
Customer responsibility.
WARNING
Door installation must meet ANSI/BHMA
standards as well as any applicable local
building codes.
.. Conditions prior to installing doors.
. System setup (Chapter ) performed for each
ED operator.
. Overhead arms rotated to  open position or
greater.
.. Floor pivots installed by customer.
. Floor pivots installed by customer.
CAUTION
Jamb edge to floor pivot centerline distance:
 /". Reference Paa. ..
. Bottom pivot hardware installed in floor by
customer for both doors.
.. Check ED operator axle to floor pivot plumb.
NOTICE
Using plumb bob, check ED operator axle to
floor pivot plumb for each door.
.. Hang doors - reference single door installation.
. Reference steps in Chapter , single door to hang
each door.
2
2
1
1
. Perform learning cycle for each door
.. Perform learning cycle for each door.
• Reference Chapter , Para. ..
. Set power fail closing speed
.. Set power fail closing speed for each door.
• Reference Chapter .
