ES 200
32
DEEN
Door 1 activates door 2
After door 1 has been activated:
Door 1 performs and opening cycle and activates door 2 on
expiry of the preset delay time. Door 2 performs an opening
cycle but does not activate door 1 again.
Door 2 activates door 1
After door 2 has been activated:
Door 2 performs and opening cycle and activates door 1 on
expiry of the preset delay time. Door 1 performs an opening
cycle but does not activate door 2.
The pulse relaying is only activated when an activation via one
of the detectors (internal or external) has been received.
Door status contact 2 (OUT 2)
(Locking of airlock if required)
The relay contact is closed as soon as the door commences an
opening cycle. (Same function as function module with ”DCW
address 48”.)
3.F.9 Pharmacy Function (IN 2)
Basic requirements:
There is an ES 200 locking device on the pulley
• Either a bistable or monostable locking is set.
• The program switch is in OFF position.
Once the Pharmacy Function is activated, the door opens to a
preset opening width and locks in this position. As soon as the
Pharmacy Function is deactivated, the door unlocks, performs
a closing cycle and relocks in this position.
3.F.10 Panic Closing Function (IN 4) & Door status contact 1
(OUT 1)
Same function as function module with „DCW address 48”.
3.F.11 Bell contact (OUT 4)
The relay contact is closed when one or both light barriers
are interrupted. This function is deactivated while the door is
closed.
FST module
ES 200-2D!
3.FST.1 EMERGENCY OPEN pushbutton optional
Basic requirements:
• The EMERGENCY OPEN pushbutton is connected in series
with the intrinsically-safe internal detector
Function:
• Set program switch to AUTOMATIC
• Push the EMERGENCY OPEN pushbutton
• The door travels to its „open position“ and comes to a halt.
3.FST.2 KT8-switch - optional
Basic requirements:
• Program switch is set to OFF
Function:
• The door is unlocked via the KT8-switch.
• A „Night-/Bank pulse” is triggered automatically.
• The door travels to its „open position“.
• On expiry of the Night-/Bank hold-open time, the door
closes and relocks.
Basic requirements:
• Program switch is set to OFF and
• a power failure has occured
Function:
• The door is unlocked via the KT8-switch.
• The door travels to the „open position“ with the aid of the
auxiliary winding.
• The door can be closed manually and and be locked via the
KT8-switch.
Basic requirements:
• The program switch is set to AUTOMATIC
Function:
• The KT8-switch is activated.
• A Night-/Bank pulse is triggered.
• The door travels to its „open position“.
• The door closes on expiry of the Night-/Bank hold-open
time.
3.FST.3 Alarmkontakt
Basic requirements:
• There is a malfunction in the FST module.
Function:
• The potential-free contact is closed.
