Cancelling the Panic Closing Function / Quitting
Approach:
- Set program switch to OFF position.
- The system has now quit the Panic Closing Function. By
setting the program switch to OFF position, the control unit
resumes its standard functions.
3.F.4 Door status contacts
- see connection diagram
3.F.4.1 Door status contact 1 (OUT-1)
- (original setting door “open“)
The relay contact is closed when the door performs an opening
cycle, is in “open“ position or performs a closing cycle.
3.F.4.2 Door status contact 2 (OUT-2)
– (original setting door “closed“)
The relay contact is closed when the door is in “closed“
position.
3.F.4.3 Door status contact 3 (OUT-3)
– (original setting “malfunction“)
The relay contact is closed in the event of a malfunction.
3.F.4.4 Door status contact – Bell contact (OUT-4)
The relay contact is closed when one or both light barriers
are interrupted. The function is deactivated when the door is
closed.
3.F.5 Expansion module
– Setting of ”DCW address 49”
The system must be disconnected from power supply while the
DCW address of the expansion module is set or amended.
DIP switches - switch 1 must be set to ON
- switch 2 must be set to OFF
3.F.6 Airlock pulse (IN 1)
The input pulse is treated like an INTERNAL DETECTOR
pulse.
Fields of application/Information
An airlock with pulse relaying is especially suitable for
buildings where one door is installed very close to the next
door and where no detectors can be installed inside the
building as they would be activated by the door panels of the
other doors when these perform opening cycles. In this case
the control unit of the first door (the door where the external
activator has been triggered) will trigger an opening pulse at
the second door as soon as the first door has performed a
complete opening and closing cycle. The duration of the pulse
depends on the detection period of the external detector. This
pulse extension can be switched off via PDA so that the pulse
is passed on within one second.
(See connection diagram 056712-45532, page 2)
Pulse relaying via door 1
After door 1 has been activated (opening pulse):
- Door 1 opens and deactivates door 2 during its opening
cycle. (Internal and external detectors are deactivated)
As soon as door 1 is in „closed“ position, it activates door 2
(pulse relaying)
During its opening cycle, door 2 locks door 1.
Then door 2 does not activate door 1.
Pulse relaying via door 2
After door 2 has been activated(opening pulse):
- Door 2 opens and deactivates door 1 during its opening
cycle. (Internal and external detectors are deactivated)
As soon as door 2 is n „closed“ position, it activates door 1
(pulse relaying)
During its opening cycle, door 1 locks door 2.
Then door 1 does not activate door 2.
3.F.7 Locking the airlock (IN 3)
As soon as the airlock function is activated while the door is
still closed, INTERNAL and EXTERNAL DETECTOR signals
are blocked, i.e. the door does not respond to their activation
signals. An opening or closing cycle cannot be interrupted. All
airlock functions are realized via direct wiring (no bus
connection). The different functions may be realised as
follows:
Airlock function:
- Door 2 is locked during the opening cycle of door 1.
(Internal and external detectors are deactivated.)
- The locking function is disabled as soon as the door is
closed.
- Door 1 is locked during the opening cycle of door 2. (Internal
and external detectors are deactivated.)
- The locking function is disabled as soon as the door is
closed.
3.F.8 Airlock pulse (OUT 3)
The relay contact is closed for approx. 500 ms as soon as
the door has reached “closed“ position. In this airlock version
even both sliding doors may be open.
Fields of application/Information
When using the system as timed airlock, the activation time of
door 2 (e. g. the time when the door opens) has to be adjusted
with the aid of the PDA (pulse relaying). The duration of the
pulse depends on the detection of the external detector. This
pulse extension can be switched off via PDA so that the pulse
is limited to one second. The timed airlock is no „real“ airlock
system, as also both doors can be open in this function. It is
especially suitable for application in hospitals with long
corridors or workshops with vehicle traffic on the corridors.
(See connection diagram 056712-45532, page 3)
