ES 200
30
DEEN
3.9 EMERGENCY CLOSING in the event of a power failure
(optional)
ES 200
Easy
/ ES 200 / ES 200 CO48:
Basic requirements:
The rechargeable battery pack (optional) has been
connected.
• The EMERGENCY CLOSING FUNCTION is adjusted.
Approach:
Set the program switch to AUTOMATIC, EXIT ONLY,
PARTIAL OPEN or PERMANENT OPEN position.
• The door is in ”open” position
• Remove power plug (power failure).
• The door travels to ”closed” position with the aid of the
rechargeable battery pack.
3.10 EMERGENCY OPERATION in the event of a power
failure.
ES 200:
Basic requirements:
The EMERGENCY OPERATION FUNCTION is
set: „A“ =
• The rechargeable battery pack (optional) is connected.
Function:
As soon as the system is activated the sliding panels move at
low (creep) speed.
• Furthermore all functions remain operational until the
rechargeable battery pack (optional) is empty.
Function module
ES 200 / ES 200-2D
Function module DIN 18650 see 057015 45532
3.F.1 Additional functions may be set/selected with the aid of
the function module.
The following additional functions are available:
- 3.F.2 Protection of secondary closing edges
- 3.F.2 Protection of main closing edge
- 3.F.3 Panic Closing Function
- 3.F.4 Door status contacts
- 3.F.6 Airlock Function
- 3.F.9 Pharmacy Function
The functions may be connected via two different DCW
addresses.
The system must be disconnected from power supply
while the DCW address of the function module is set or
amended.
Setting the DCW address:
Set both DIP switches of the control unit to OFF position.
- The DCW address 48 is now set.
EN
3.F.2 Protection of secondary closing edges via ”DCW address
48” (IN 1 and IN 2) see connection diagram of function
module
Presence sensors monitor the movement range behind the
sliding panels in ”open” direction. (For example the active
panel that moves towards the wall for systems without safety
screens.)
If a person or an object enters the detection range of the
presence sensor, the opening cycle is stopped and the door
will not open until the obstruction has been removed.
Protection of main closing edge (IN 3) see connection diagram
of function module
Presence sensors monitor the movement range between the
sliding panels while the door closes. If a person or an object
enters the detection range of the presence sensor, the closing
cycle is reversed into an opening cycle.
3.F.3 Adjustment of Panic Closing Function (IN 4) see wiring
diagrams of function module
The Panic Closing Function is subject to special legal
provisions, therefore the provisions of the relevant
country have to be observed.
The Panic Closing Function has to be adjusted via the PDA for
safety reasons.
The Panic Closing Function must be triggered via safety
deactivation (Totman system).
Basic requirements:
- The Panic Closing Function must be activated.
Function:
- Press and hold the pushbutton to close the door. The door
will only close while the pushbutton is activated (the contact
is closed).
- The door will close immediately (it will even reverse an
opening cycle).
- The safety functions such as blocking recognition, light
barriers and radar motion detectors are deactivated. The door
closes and locks.
- In case the door is blocked by a person or an obstacle during
this closing cycle, the door will press with all its might against
the obstruction in order to close. The door will not respond
to an activation via NIGHT-/BANK, INTERNAL or EXTERNAL
DETECTOR as soon as it has reached „closed“ position.
- This procedure can only be stopped when the motor is over-
loaded. The motor will switch off for 10 seconds following 10
seconds of constant operation. On expiry of these 10-seconds,
the door will try to close until it succeeds to clos and lock (the
blocking is removed).
In case the motor overloads, this error may be redeemed by
setting the program switch to OFF position. This sets the
waiting period to ”0” in order to enable a prompt response of
the door.
