3.3 Internal detector
Checking the function. Basic requirements:
• The internal detector has been connected.
• The program switch must be set to AUTOMATIC,
EXIT ONLY or PARTIAL OPEN position.
The operator responds as follows:
When a person or an obstacle enters the detection range of
the sensor, the door travels to ”open” position and closes on
expiry of the hold-open time.
3.4 Night-/Bank activator (optional)
ES 200 Easy :
Checking the function. Basic requirements:
• The Night-/Bank activator has been connected.
• The emergency power supply has been activated (The
rechargeable battery pack has been connected)
Approach:
• Activate the contact of the switch so that it is permanently
activated.
• The door remains open as long as the switch is activated.
The door closes on expiry of the Night-/Bank hold-open time
as soon as the contact is interrupted.
ES 200 Easy / ES 200 / ES 200-2D / ES 200 CO48 /
DAC 300:
Checking the function. Basic requirements:
• The Night-/Bank switch has been connected.
• The program switch is set to OFF position.
Approach:
• Trigger an opening pulse via the Night-/Bank activator.
• The door is unlocked and performs an opening cycle.
• A permanent pulse activates the “PERMANENT OPEN”
function.
• After the user has passed the door or on expiry of the
Night-/Bank hold-open time, the door performs a closing
cycle and is locked in “closed“ position.
3.5 Monitoring of closing and opening force
3.5.1 Obstacle during closing cycle:
• The door runs into an obstacle during a closing cycle.
The operator responds as follows:
• The closing cycle is reversed into an opening cycle.
• The door travels to full opening width. The door closes at
low (creep) speed on expiry of the adjusted hold-open time.
This procedure is repeated until the obstacle has been
removed.
3.5.2 Obstruction during opening cycle:
If the door panels run into an obstruction, the door will stop
and perform a further opening attempt at low (creep) speed.
If the obstruction is still present, the door will stop again.
After a total of six opening attempts, the door will close. Once
the obstruction has been removed, the next opening cycle is
performed at low (creep) speed. Then the door resumes
operation at the adjusted speed.
3.6. EMERGENCY OFF pushbutton (optional)
Basic requirements:
• The program switch must be set to AUTOMATIC,
PARTIAL OPEN, EXIT ONLY, OFF (not locked) or
PERMANENT OPEN.
Approach:
• Press the EMERGENCY OFF pushbutton.
• The motor circuit is interrupted.
• The door panels come to a halt and can be moved manually.
3.7 Locking device (NO rod lock system) optional
The door is locked while it is closed when the program switch
is set to OFF.
3.8. EMERGENCY OPEN FUNCTION in the event of a power
failure (optional)
ES 200 Easy / ES 200 / ES 200 CO48:
Basic requirements:
The rechargeable battery pack (optional) is connected.
• The EMERGENCY OPEN FUNCTION is adjusted.
In the event of a power failure:
If the program switch is in OFF position:
• The door will remain closed.
If the program switch is in AUTOMATIC, PARTIAL OPEN or
EXIT ONLY position:
• An automatic emergency opening is performed.
• The door will be opened with the aid of the rechargeable
battery pack (optional).
The door may be manually unlocked and opened from the
inside.
