2. Settings
The control unit is preset with basic settings (original
settings). If you require another setting, you will have to
implement this either with the aid of the buttons next to the
7-segment display on the control unit (see parameterisation
instructions) or via PDA (Personal Digital Assistant).
General information concerning the original settings.
The system should only be reset to original settings in
case that several settings have been changed and the
door no longer works properly.
ES 200
Easy
:
• Set program switch to AUTOMATIC
ES 200 / ES 200 2D / ES 200 CO48 / DAC 300:
• Set program switch to OFF
• Open the door leaves to 50 p.c.:
• Please consider the country-specific settings.
• Connect power plug.
• Press and hold the SERVICE button until the door performs
a closing cycle.
ES 200
Easy
/ ES 200 / ES 200 CO48:
• In case the door starts an opening cycle, press the minus
button on the control unit to change the rotation direction of
the motor.
ES 200 2D
• Both the polarity of the leads (white – brown) of the motor
connection and those of the auxiliary motor have to be
reversed.
• As soon as the power supply has been switched on, the con-
trol unit powers up and the security checks are performed.
• An 8 blinks on the 7-segment display. When the 8 blinks
twice, the original settings have been restored.
ES 200
Easy
/ ES 200 / ES 200 2D / ES 200 CO48 /
DAC 300:
• Following the restoring of the original settings,
differing settings (e.g. motor type, door type)
have to be made manually either via the buttons
on the control unit or via PDA (parameterisation)
and a learning cycle has to be performed (see 1.3.5).
3. Functional tests
Please note:
All connected activators must be checked in each program
switch position.
The activators must be adjusted according to the respective
installation instructions/documentation texts.
3.1 Light barriers
Automatic light barrier self-test (internal test via control unit)
The light barriers are automatically tested before each closing
cycle. If the test fails (the door does not close) the system
must be checked by a service engineer.
The movement range between the sliding panels is monitored
by light barriers. If a person or an object enters the movement
range or detection range of the light barriers, the closing cycle
is reversed into an opening cycle and the door remains open
until the monitored area is free and the hold-open time has
expired.
Manual light barrier check with test piece
a) during closing cycle:
Interrupt one light barrier after the other during the closing
cycle. The respective LED on the control unit goes out and the
closing cycle is reversed.
b) while the door is open:
Interrupt the light barriers for several seconds while the door
is open.
The door should remain open for as long as the light barriers
are interrupted. Once the light barriers are uninterrupted, the
door should close on expiry of the preset hold-open time.
3.2 External detector
The external detector is a radar motion detector that responds
to movements. The system is activated by approaching people
or objects.
Functional test.
Basic requirements:
• The external detector is connected.
• The program switch is set to AUTOMATIC or PARTIAL OPEN
position.
Function:
If a person or an object comes within the range of the sensor,
the door opens, and then closes on expiry of the hold-open
time.
EN
