1.06: CORTEX - Connector Pin Details
The table below gives connection details between CORTEX Controller Input/output and Connector Pins.
- PROGRAM: 109-0285
- REVISION: 20191118
ASL – (7000 O.I.G.A.I / O.I.N / Multipack / Python) Unit
Automate
d Side
Loader
Unit
Connect
or
Pin-Out
Detail
s
STANDARD INPUTS
A01
GRABBER OPEN PUSH BUTTON
%IX0.01
P1-27
A02
SIDE DOOR CLOSED PROX.
%IX0.02
P1-9
A03
TAILGATE CLOSED PROX.
%IX0.03
P1-28
A04
PACKER FULL EXTEND PROX.
%IX0.04
P1-10
A05
FILTER PRESSURE SWITCH
%IX0.05
P1-29
A06
PACKER FULL RETRACT PROX.
%IX0.07
P1-30
A07
LOW TORQUE PRESSURE SWITCH
%IX0.12
P1-20
A08
PACKER EXTEND PUSH BUTTON
%IX0.14
P1-21
A09
SYSTEM POWER SWITCH
%IX0.15
P1-38
A10
CHASSIS NEUTRAL SIGNAL
%IX1.04
P1-19
A11
HYDRAULIC PUMP ENABLE PUSH BUTTON
%IX1.05
P1-55
A12
PACKER RETRACT PUSH BUTTON
%IX1.06
P1-18
A13
GRABBER FULL OPEN PROX.
%IX2.00
P1-48
A14
TAILGATE CONTROL PROX.
%IX2.02
P1-31
A15
GRABBER CLOSE PRESSURE SWITCH
%IX2.03
P1-50
A16
CHASSIS SERVICE BRAKE SIGNAL
%IX2.04
P1-51
A17
PACKER PRESSURE SWITCH
%IX2.05
P1-52
A18
GRABBER CLOSE PUSH BUTTON
%IX2.06
P1-16
A19
LIFT RETRACTED PROX.
%IX2.07
P1-35
MULTI-FUNCTION INPUTS
B01
IN-CAB ENABLE, STROBE (FUNCTION HAS BEEN REMOVED)
%IX0.00
P1-8
B02
HYDRAULIC OIL TEMP. 0.5-4.5 VDC ANALOG
%IX0.00
P1-8
