Body Controller Software
118
B03
LIFT LOWERED PROX (PYTHON UNIT)
%IX0.06
P1-11
B04
THROTTLE ADVANCE SWITCH (MULTIPACK UNIT)
%IX0.06
P1-11
B05
LIFT RAISED PROX (7000 O.I.G.A.I. AND O.I.N. UNITS)
%IX0.06
P1-11
B06
PACKER TRAVEL POSITION SWITCH
%IX0.13
P1-2
B07
TRASMISSION TEMPERATURE SWITCH
%IX0.13
P1-2
B08
IN-CAB ENABLE, REAR STROBE
%IX1.07
P1-37
B09
IN-CAB ENABLE, TURN SIGNAL
%IX1.07
P1-37
B10
OIL LEVEL SWITCH
%IX1.07
P1-37
B11
BODY DOWN PROX. (NON-MULTIPACK UNITS)
%IX2.01
P1-49
B12
TAILGATE BUZZER SWITCH (MULTIPACK UNIT)
%IX2.01
P1-49
STANDARD OUTPUTS
C01
REAR STROBE (IN-CAB ENABLE ACTIVATED)
%QX0.00
P1-44
C02
PACKER PUMP (P2)
%QX0.02
P1-46
C03
LIFT RETRACT SOLENOID (MULTIPACK AND PYTHON UNIT)
%QX0.03
P1-47
C04
PACKER RETRACT SOLENOID
%QX0.04
P1-36
C05
PACKER EXTEND SOLENOID
%QX0.05
P1-54
C06
LIFT RAISE SOLENOID (MULTIPACK AND PYTHON UNIT)
%QX0.07
P1-53
C07
FILTER BYPASS INDICATOR
%QX0.08
P1-39
C08
LIFT EXTENDED INDICATOR
%QX0.09
P1-3
C09
TAILGATE OPEN INDICATOR
%QX0.12
P1-41
C10
LIFT PUMP (P1)
%QX0.14
P1-43
C11
IN-CAB ALARM
%QX0.15
P1-4
MULTI-FUNCTION OUTPUTS
D01
BODY RAISED (PYTHON)
%QX0.01
P1-45
D02
THROTTLE ADVANCE (MULTIPACK UNIT)
%QX0.01
P1-45
D03
TAILGATE HYDRAULIC POWER (MULTIPACK UNIT)
%QX0.06
P1-17
D04
FRONT STROBE (IN-CAB ENABLE ACTIVATED) (NON-MULTIPACK UNITS)
%QX0.06
P1-17
D05
OUT OF DIMENSION WM
%QX0.06
P1-17
D06
GRABBER CLOSE SOLENOID
%QX0.10
P1-40
