Dräger 8413417 - Intended Use; Overview

English / US English
24
Instructions for Use Air Compressor
Intended Use
Air compressor supplying compressed air for
medical ventilators.
Overview
A Orange LED Temp indicates when
temperature is too high
B Green LED indicates operation or standby
C Filter mat
D On/Off switch
E Power cable
F Fuses (T1, T2)
G Operating hours counter
H Rating plate
I Exhaust air conduct
J Connection for Air compressed gas hose from
the central gas supply system (standby devices
only)
K Coupling for Air compressed gas hose from the
ventilator
001
A B
002
C
D
E
F
K
J
I
G
H
