64 Instructions for use | LAR 8000
en | Technical data
11.2 Mixed gas operation mode
11.3 Oxygen operation mode
11.4 Compressed gas cylinders
Oxygen cylinders:
Mixed-gas cylinders:
Dimensions (L x W x D) 435 x 340 x 190 mm
(incl. oxygen cylinder)
Circuit Semi-closed
Gas type Nitrox B mixture
(60±1 Vol.% O
2 and 40 Vol% N2)
Nitrox C mixture
(40±1 Vol.% O
2 and 60 Vol% N2)
Nitrox D mixture
(32.5±1 Vol.% O
2 and 67.5 Vol% N2)
Gas supply Constant dosage
Nitrox B mixture 5.0 to 6.5 L/min
Nitrox C mixture 10.0 to 13.0 L/min
Nitrox D mixture 16.0 to 19.0 L/min
Dive time Depending on the dosage used and the
volume of the mixed-gas cylinder.
Circuit Closed
Gas type Pure oxygen according to EN 12021
Gas supply Via lung demand valve
Dive time Depending on oxygen consumption
Oxygen cylinder, 1.5 L (T 80220)
Steel
200 bar/G 3/4"/Ø 115 mm
Approx. 2.8 kg empty/black/TÜV
Oxygen cylinder, 2 L, (T 80222)
Composite
Non-magnetic version, based on
STANAG 2897 class A
200 bar/G 3/4"/Ø 135 mm
Approx. 2 kg empty/black/TÜV
Oxygen cylinder, 1.9 L, (4059311)
Aluminum, anodized
3000 psi/CGA 540/Ø 133 mm Approx.
3.4 kg empty/black/DOT 3AL
Oxygen cylinder, 1.9 L, (4054802)
Aluminum, varnished
3000 psi/CGA 540/Ø 133 mm Approx.
3.4 kg empty/black/DOT 3AL
Mixed-gas cylinder, 1.9 L (T 17353)
Aluminum
200 bar/G 3/4"/Ø 134 mm
Approx. 3.4 kg empty/black/DOT 3AL
Mixed-gas cylinder, 2.7 L (T 16808)
Aluminum
200 bar/G 3/4"/Ø 117 mm
Approx. 4.7 kg empty/black/TÜV
