Dräger PEX 3000 User Manual

Commissioning
Factory defaults
The control unit is delivered with the following default settings
Measuring range 0 to 1
Alarm 1 Undetermined value/rising/non-latching
Alarm 2 Undetermined value/rising/non-latching
Alarm 3 Undetermined value/rising/non-latching
Fault Non-latching/ fixed at 3.2mA
Calibration Undetermined
Set measuring range
Altering the setting of the DIL switch on the display board changes the measuring
range. The following table details all available measuring ranges
For Display board with Rev x.00 software:
Range D.P.
SW1
- A
SW1
- B
SW1
- C
SW1
- D
SW1
- E
SW1
- F
0 - 1 2 OFF OFF OFF OFF OFF X
0 - 3 2 ON OFF OFF OFF OFF X
0 - 5 2 OFF ON OFF OFF OFF X
0 - 10 2 ON ON OFF OFF OFF X
0 - 25 1 OFF OFF ON OFF OFF X
0 - 30 1 ON OFF ON OFF OFF X
0 - 50 1 OFF ON ON OFF OFF X
0 - 100 1 ON ON ON OFF OFF X
0 - 200 0 OFF OFF OFF ON OFF X
0 - 250 0 ON OFF OFF ON OFF X
0 - 300 0 OFF ON OFF ON OFF X
0 - 500 0 ON ON OFF ON OFF X
0 - 1000 0 OFF OFF ON ON OFF X
0 - 2000 0 ON OFF ON ON OFF X
0 - 2500 0 OFF ON ON ON OFF X
0 - 3000 0 ON ON ON ON OFF X
0 - 5000 0 OFF OFF OFF OFF ON X
0 - 9999 0 ON OFF OFF OFF ON X
TWA
X X X X X
ON/
OFF
Issue 4 03/09/04
9 of 29
