Order list
Order list
Name and description Part-No.
Transmitter
Transmitter PEX 3000, Typ XTR 0000
small housing, measuring range 0 to 100 % LEL
83 18 280
Transmitter PEX 3000, Typ XTR 0010
small housing, measuring range 0 to 10 % LEL
83 18 290
Transmitter PEX 3000, Typ XTR 0090
small housing, Remote-Transmitter
83 18 380
Transmitter PEX 3000, Typ XTR 0001
big housing, measuring range 0 to 100 % LEL
83 18 360
Transmitter PEX 3000, Typ XTR 0011
big housing, measuring range 0 to 10 % LEL
83 18 370
Transmitter PEX 3000, Typ XTR 0091
big housing, Remote-Transmitter
83 18 390
Sensig head SE Ex PR M
0 to 100 % LEL, to combine with XTR 0090 / 0091
68 09 758
Sensing head SE Ex LC M
0 to 10 % LEL, to combine with XTR 0090 / 0091
68 10 486
Accessories
Calibration adapter 68 06 978
Calibration chamber
to produce flammable vapours in the range of approx.
50 % LEL
68 02 206
Dust filter
for DrägerSensor Ex PR M (only for type XTR 0000 and
XTR 0001), packing unit 10 pcs.
68 10 537
Special tool
to open the spring terminals, plastic
83 18 376
Accessories
1)
1)
The storage time of the spare parts is unlimited. This is also valid for the spare part sensors
as long as they are stored in their original package under conditions specified on page 25.
DrägerSensor Ex PR M
spare part sensor for type XTR 0000 and XTR 0001
68 09 225
DrägerSensor Ex LC M
spare part sensor for type XTR 0010 and XTR 0011
68 10 350
Converter Module ET 420
complete
83 18 377
