Maßzeichnung Standardausfürung
Dimensional drawing of standard type
Schaltfunktion/Function:
in Ruhestellung gesperrt - NC.
normally closed - NC.
Anschlußplan / Connection diagram
Für Wechsel- und
Gleichspannung.
For AC and DC.
Erdung oder Schutzschaltung nach Vorschrift des zuständigen EVU.
Grounding or earthing of the protective circuit in accordance with
regulations of the responsible electric supply company.
Absicherung entsprechend der Stromaufnahme vorsehen.
Appropiate protection according to the power-consumption.
Alle Angaben sind freibleibend und unverbindlich / All technical specifications are without obligation!
Schaltfunktion/Function:
in Ruhestellung geöffnet - NO.
normally open - NO.
Weitere Ventilausführungen / Valve options
Stromlos geöffnet= NO Handbetätigung= HA
Non energised open= NO Manual operation= HA
Dichtung= EPDM, PTFE Öl- und fettfrei= OF
Seal= EPDM, PTFE Free of oil and grease= OF (for oxygen applications)
Andere Durchflußmedien und Viskositäten Buntmetallfrei= BF
Varying medium and viscosity ranges Freee of non-ferrous metal= BF
Abweichende Temperaturen und Drücke P-Sammelleisten
Varying temperature and pressure ranges Manifold system
Ventilgehäuse= Rotguß Ex-Schutz= Ex II 2G
Body material= Bronze Explosion proof=
*AbDN5,0L=50mm
FromDN5,0L=50mm
EEx md II cT4, T5 oder T6
Ex II 2G EEx md II cT4, T5 or T6
Magnet
Solenoid .182 .032/ .012/ .148/ .012-NO .692-NO .322/.328
Type A523. A524. A523. A524. A525. A526. A523. A524. A525. A526. A523.-5. A526.
G 1/8 1/4 1/8 1/4 3/8 1/2 1/8 1/4 3/8 1/8-3/8
A 15 2025253030252530305050
B 30x30 30x30 35x32 35x32 35x32 35x32 35x35 35x35 35x35 35x35
C 53 5358585858666666667676
D - M5 M6 M6 M6 M6 M6 M6 M6 M6
H 55 60 80 80 85 90 95 95 100 105 148 152
K 47,5 52,5 67,5 67,5 70 70 82,5 82,5 85 90 135 135
L 32 40 40 *40 50 60 40 *40 50 60 60 60
M 30 3040404040505050505959
N 5 510101010101010101616
T - - 15,5 15,5 15,5 15,5 15,5 15,5 15,5 15,5 - -
U - 15,5 15,5 15,5 15,5 15,5 15,5 15,5 15,5 35 35
Pg M20x1,5
kg 0,3 0,35 0,55 0,6 0,65 0,75 0,8 0,9 1,0 1,2 2,0 2,4
1/2 1/2
M6 M6
-
M20x1,5 M20x1,5 M20x1,5 M20x1,5 M20x1,5 M20x1,5 M20x1,5 M20x1,5 M20x1,5 M20x1,5 M20x1,5
ø63 ø63
AC
DC
