Vigor2912 Series User’s Guide
93
Line Speed
If your choose According to Line Speed as the Load
Balance Mode, please type the line speed for downloading
and uploading for such WAN interface. The unit is kbps.
VLAN Tag insertion
Enable – Enable the function of VLAN with tag.
The router will add specific VLAN number to all packets on
the WAN while sending them out.
Please type the tag value and specify the priority for the
packets sending by WAN1.
Disable – Disable the function of VLAN with tag.
Tag value – Type the value as the VLAN ID number. The
range is form 0 to 4095.
Priority – Type the packet priority number for such VLAN.
The range is from 0 to 7.
Active Mode
Choose Always On to make the WAN2 connection being
activated always.
Backup Type
If you choose Backup as the Active Mode, Backup Type
will appear. Please specify which WAN will be treated as
the Backup WAN.
When any of selected WAN disconnect – Such backup
WAN will be activated when any master WAN interface
disconnects.
When all of selected WAN disconnect – Such backup
WAN will be activated only when all master WAN
interfaces disconnect.
Load Balance: Check this box to enable auto load balance
function for such WAN interface.
When the data traffic is large, the WAN interface with the
function enabled will balance the data transmission
automatically among all of the WAN interfaces in
connection status.
After finished the above settings, click OK to save the settings.
