Vigor2912 Series User’s Guide
121
4
4
.
.
1
1
.
.
5
5
L
L
o
o
a
a
d
d
-
-
B
B
a
a
l
l
a
a
n
n
c
c
e
e
P
P
o
o
l
l
i
i
c
c
y
y
This router supports the function of load balancing. It can assign traffic with protocol type, IP
address for specific host, a subnet of hosts, and port range to be allocated in WAN1, WAN2,
and WAN3 interface. The user can assign traffic category and force it to go to dedicate
network interface based on the following web page setup. Twenty policies of load-balance are
supported by this router.
Note: Load-Balance Policy is running only when WAN1, WAN2 and WAN3 are
activated.
Available settings are explained as follows:
Item Description
Index
Click the number of index to access into the load-balance
policy configuration web page.
Enable
Check this box to enable this policy.
Protocol
Use the drop-down menu to change the protocol for the
WAN interface.
WAN
Use the drop-down menu to change the WAN interface.
Src IP Start
Displays the IP address for the start of the source IP.
Src IP End
Displays the IP address for the end of the source IP.
Dest IP Start
Displays the IP address for the start of the destination IP.
Dest IP End
Displays the IP address for the end of the destination IP.
Dest Port Start
Displays the IP address for the start of the destination port.
Dest Port End
Displays the IP address for the end of the destination port.
Move UP/Move Down
Use Up or Down link to move the order of the policy.
To Next Page
