Vigor2912 Series User’s Guide
137
4. Go to Diagnostics and choose Routing Table to verify current routing table.
4
4
.
.
2
2
.
.
4
4
V
V
L
L
A
A
N
N
Virtual LAN function provides you a very convenient way to manage hosts by grouping them
based on the physical port. You can also manage the in/out rate of each port. Go to LAN page
and select VLAN. The following page will appear. Click Enable to invoke VLAN function.
Note: Settings in this page only applied to LAN port but not WAN port.
Available settings are explained as follows:
Item Description
Enable
Click it to enable VLAN configuration.
LAN
P1 – P4 – Check the LAN port(s) to be grouped under the
selected VLAN.
