Vigor2912 Series User’s Guide
153
Available settings are explained as follows:
Item Description
Enable Open Ports
Check to enable this entry.
Comment
Make a name for the defined network application/service.
WAN Interface
Specify the WAN interface that will be used for this entry.
WAN IP
Specify the WAN IP address that will be used for this entry.
This setting is available when WAN IP Alias is configured.
Local Computer
Enter the private IP address of the local host or click
Choose PC to select one.
Choose PC - Click this button and, subsequently, a window
having a list of private IP addresses of local hosts will
automatically pop up. Select the appropriate IP address of
the local host in the list.
Protocol
Specify the transport layer protocol. It could be TCP, UDP,
or ----- (none) for selection.
Start Port
Specify the starting port number of the service offered by
the local host.
End Port
Specify the ending port number of the service offered by
the local host.
