Draytek Vigor2912 Series User Manual

Vigor2912 Series User’s Guide
189
MAC Address
Type the MAC address of the network card which will be
controlled.
Start IP Address
Type the start IP address for Single Address type.
End IP Address
Type the end IP address if the Range Address type is
selected.
Subnet Mask
Type the subnet mask if the Subnet Address type is
selected.
Invert Selection
If it is checked, all the IP addresses except the ones listed
above will be applied later while it is chosen.
4. After finishing all the settings here, please click OK to save the configuration. Below is
an example of IP objects settings.

Draytek Vigor2912 Series Specifications

General

Brand	Draytek
Model	Vigor2912 Series
Category	Network Router
Language	English
