Vigor2912 Series User’s Guide
303
Below shows Wireless LAN>>WPS web page:
Available settings are explained as follows:
Item Description
Enable WPS
Check this box to enable WPS setting.
WPS Status
Display related system information for WPS. If the wireless
security (encryption) function of the router is properly
configured, you can see ‘Configured’ message here.
SSID
Display the SSID1 of the router. WPS is supported by
SSID1 only.
Authentication Mode
Display current authentication mode of the router. Only
WPA2/PSK and WPA/PSK support WPS.
Configure via Push
Button
Click Start PBC to invoke Push-Button style WPS setup
procedure. The router will wait for WPS requests from
wireless clients about two minutes. The WPS LED on the
router will blink fast when WPS is in progress. It will return
to normal condition after two minutes. (You need to setup
WPS within two minutes)
Configure via Client
PinCode
Please input the PIN code specified in wireless client you
wish to connect, and click Start PIN button. The WPS
LED on the router will blink fast when WPS is in progress.
It will return to normal condition after two minutes. (You
need to setup WPS within two minutes)
