User Manual - ProVideo GUI v1.2.4
1 Values of current color conversion matrix.
2 Presets for color conversion. The default is Rec.709, Rec.2020 is usually used for
UHD video or HDR content.
3 Fine tuning of the matrix red balance.
4 Fine tuning of the matrix blue balance.
5 Load / save the color conversion matrix from / to file.
6 Set SDI output range to legal or extended. In legal range mode, the black and
white levels can be fine tuned (see below).
7 Sets SDI black level (extend dynamic).
8 Sets SDI while level (extend dynamic).
Note: Settings 1 to 5 are only visible when the Engineering Mode is activated in the GUI
Settings.
Note: Settings 6 to 8 are disabled and the output range is fixed to “Extended Range” if the
HDR / LOG mode is set to S-Log3 (see chapter 4.1, point 21).
Instead of manually changing the color conversion matrix it is advised to use the “Color
Space” setting in the in-out tab (see chapter 4.1, point 23). When switching the color space
the color conversion matrix will automatically be set to it’s default values for the selected
color space.
