DRC 242-A 2007-08-03 Page 18 DC3 with SEM Installation Instructions
17. Finalizing Connections
This completes installation of the DriveCam Event Recorder and the primary and secondary triggers of
the UM05 device. If you are planning to use the output feature of the UM05, proceed to the next page to
continue with the installation.
If you are not planning to use the output feature of the UM05, cap the two output wires (blue and yellow
wires) on the UM05 switch cable. Coil all excess wiring and secure it with the UM05 in a safe location.
