DRC 242-A 2007-08-03 Page 9 DC3 with SEM Installation Instructions
9. Plug the cables into the CAT and UM05
The best place to keep the Cable Access Terminal (CAT) and the Universal Module (UM05) is usually
under the dashboard. Find a suitable location to connect and secure the wiring and equipment.
Step 1 Plug all cables into the Cable Access Terminal (CAT).
Step 2 Plug the UM05 Interconnect Cable into the Universal Module (UM05).
Step 3 Plug the UM05 Switch Cable into the Universal Module (UM05).
Do not secure the CAT or UM05 permanently in place until after the connections have been tested.
