Tamarisk
®
Camera Control Software User Guide
Automatic
Calibration
Period (in minutes)
Set Period
Sets time between calibrations
Sets new calibration period (default is 5 minutes)
Setting the “Autocal Enabled” button to “0” turns auto calibration
off.
Click “Save Settings” to save changes to the camera’s non-
volatile memory
Calibration
Status
Provides the current
calibration status
The camera will periodically update the calibration status. This is
especially important if the user has disabled the automatic
calibration by clicking “Autocal Enabled.”
Orientation
Normal
Flip Vertically
Flip Horizontally
Flip Vertically/
Horizontally
Normal display mode
Flips the image from top to bottom
Flips the image from left to right
Flips the image from top to bottom and left to right
Click “Save Settings” to save changes to the camera’s non-
volatile memory
Shutter
Shutter Open
Shutter Closed
Opens shutter
Closes shutter
Polarity
White Hot
Black Hot
Hot pixels are shown as white and cold pixels are shown as black
Hot pixels are shown as black and cold pixels are shown as white
Click “Save Settings” to save changes to the camera’s non-
volatile memory
Symbology
Enable on-screen
indicators
Enable DRS logo
Start-up screen duration
1-pt indicator display
time
Enables/disables zoom, 1-pt calibration, and polarity indicators.
The 1-pt calibration indicator also requires the 1-pt indicator
display time to be set greater than 0 to be enabled.
Enables/disables the DRS logo.
Sets the time in seconds that the DRS splash screen is displayed
on camera power-up.
Sets the time in seconds that the 1-pt calibration indicator will be
shown prior to a shutter event.
Changes on the Symbology task pane are automatically saved to
the camera’s non-volatile memory
5.2.1 Calibration (One-Point Calibration) Non-Uniformity Correction
To optimize a thermal scene, the processor software performs NUC or 1-Point calibration of the
video images through internal calculations. To provide the best possible image, a non-uniformity
correction is performed based on information provided by factory calibration, user-commanded 1-
point calibrations, and bad pixel replacement (BPR) algorithms. Initiating a NUC activates a one-
point single-temperature correction sequence that will reset the level offset of each pixel to
improve overall image uniformity and contrast.
A NUC is performed automatically at start up, per the AutoCal setting and when the FPA
temperature transitions into another temperature zone – these zones are static with a
