Specifications
8
3.4 INPUTS
3.4.1 DIGITAL INPUTS
Number 4
Arrangement Contact between input terminal and the module’s plant supply negative terminal
Low level threshold 3.0V minimum
High level threshold 4.1V maximum
Maximum input voltage +60V DC with respect to module’s plant supply negative terminal
Minimum input voltage -2V DC with respect to module’s plant supply negative terminal
Contact wetting current 6mA ±1mA
Open circuit voltage 12V ±1V
3.5 OUTPUTS
3.5.1 CONFIGURABLE NORMALLY OPEN RELAY OUTPUTS A & B
Number 2 (Configurable outputs A & B)
Type Volts free normally open contacts
Rating 8A @ 35VDC
3.5.2 CONFIGURABLE CHANGEOVER RELAY OUTPUTS C & D
Number 2 (Configurable output C)
Type Volts free change over contacts.
Rating 8A @ 35VDC
3.5.3 CONFIGURABLE OUTPUTS E - H
Number 4
Type Fully configurable, DC outputs rated at DC voltage
Rating 8A @ 35VDC
Protection Protected against over current & over temperature. Built in load dump feature.
3.6 COMMUNICATION PORTS
USB Port USB2.0 Device for connection to PC running DSE configuration suite only
