Installation

3.11 INSTALLATION

The DSE892 is designed to be mounted within a control panel, either on the panel DIN rail utilising

the integral mounts, or chassis mounted, utilising the mounting holes. For dimension and mounting

details, see the section entitled Specification, Dimensions elsewhere in this document.

3.12 USER CONNECTIONS

3.12.1 CONNECTOR A – DC SUPPLY AND CONFIGURABLE OUTPUTS

Terminal

Function

Recommended size

1 DC supply positive 1.0mm² (AWG18)

2 DC supply negative 1.0mm² (AWG18)

3 RESERVED

4 RESERVED

5 RESERVED

6 RESERVED

3.12.2 CONNECTOR B – RS485

Terminal

Function

Recommended size

A RS485 A 0.5mm² (AWG20)

B RS485 B 0.5mm² (AWG20)

SCR RS485 SCREEN
