no. Description
1 Speed
It is displayed increased by 5% and together with the set unit of measurement (km/h or mph).
2 Gear
3 Rev counter (page 137)
4 Engine Coolant temperature (°C or °F)
The temperature display range goes from +40 °C to +120 °C (+104 °F ÷ +248 °F).
If the temperature is below +40°C (+104°F), “LO” is displayed, whereas if it is above +120 °C (+248 °F),
“HI” is displayed flashing red.
In case of overheating, if possible, it is recommended to ride at reduced speed to allow the
cooling system to lower the engine temperature. If this is not possible due to conditions, stop
and turn the engine
If the motorcycle continues to be used when the engine is overheated, severe damage may occur.
When the engine temperature returns to normal, continue riding by frequently checking the in‐
strument panel indication.
5 Fuel level
6 Function menu (page 156)
7 DTC level indication
8 ABS level indication
9 DQS level indication (if any)
133
