Side stand
Place the motorcycle on the side stand only
when you are not going to use it for periods of
time. Before lowering the side stand, make sure that
the bearing is hard and flat.
The position of the side stand is identified on
the instrument panel by the warning light (A). When
the warning light is on, the side stand is lowered (and
the engine is inhibited).
Do not park on or pebbled ground or on asphalt
melted by the sun, etc. or else the motorcycle may
fall over. When parking downhill, always position the
motorcycle with the rear wheel facing downhill.
To pull down the side stand, hold the motorcycle
handlebar with both hands and push down on the
side stand (1) with your foot until it is fully extended.
Tilt the motorcycle until the side stand is resting on
the ground.
To move the side stand to its rest position (horizontal
position), lean the motorcycle to the right while
the thrust arm (1) with your foot.
Fig 42
Fig 43
69
