Engine
Ducati Twin cylinder, L-type,
Desmodromic timing system, 4 valves per cylinder,
liquid cooling.
Bore: 94 mm (3.7 in)
Stroke: 67.5 mm (2.66 in)
Total displacement: 937 cu. cm (57.18 cu in)
Compression ratio: (12.6±0.5):1
Lubrication: lobe-type oil pump with built-in by-pass
valve and oil cooler
Maximum power at (EU) Regulation no.
134/2014, Annex X, kW/HP:
83 kW/113 HP at 9,000
rpm
Maximum torque at (EU) Regulation no.
134/2014 Annex X:
94 Nm / 9.6 Kgm at 6,750
rpm
Max. rotation speed:
10200
rpm.
Do not exceed the specified rpm limits in any
running conditions.
The indicated power/torque values have been
measured with a static test bench according to type-
approval standards and match with the data
detected during type-approval process; they are
indicated in the vehicle registration document.
261
