Correct tightening of swinging arm screws (1) is
critical to rider and passenger safety.
Improper chain tension will lead to early wear of
transmission
To ensure the best and long life of
the chain, please follow the information related to
chain cleaning, lubrication, inspection and
tensioning.
Check the correspondence of the positioning marks
(2) on both sides of the swinging arm to ensure a
wheel alignment.
Fig 183
