Check the correct positioning of the seat (4).
Note
The seat lowered by 20 mm (0.79 in) or raised by
20 mm (0.79 in) compared to the standard
configuration indicated in the chapter "Overall
dimensions" can be purchased as original Ducati
accessories.
the passenger seat
Position the passenger seat (2) on the rear subframe
by tab (3) into seat (8) inside of the tool
Push the passenger seat (2) downwards to block pin
(9) into the seat lock.
Make sure the passenger seat (2) is properly
fastened by moderately pulling it up.
Take key out of the lock.
Fig 36
Fig 37
64
