Dunkirk DCBF-125 - 7 Gas Supply Piping; General

30
CAUTION
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow gas supplier’s
instructions.
• 
department.
!
NOTICE
Use of CSA approved corrugated, semi-rigid stainless
steel tubing with polyethylene jacketing is approved
for use with boilers following tubing manufacturer's
instructions.
"appliance whip" gas tubing is not
allowed per NFPA 54.
WARNING
Fire, explosion, asphyxiation and burn hazard. Boiler
piping and gas connections shall be leak tested before
placing boiler in operation. Failure to follow these
instructions and or improper installation could result in
death or serious injury.
!
Required Gas Supply Pressure
Natural Gas Liquid Propane
Min. Max. Min. Max.
3.5" w.c. 10.5" w.c. 8.0" w.c. 13.0" w.c.
(0.87 kPa) (2.61 kPa) (1.99 kPa) (3.23 kPa)
Gas Supply Required
Model Natural Gas (A) Liquid Propane (E)
DCBF-125 118 ft3.30 51 ft1.48
DCCF-150 143 ft/h (4.00 m/h) 61.15 ft/h (1.72 m/h)
DANGER
Fire Hazard. Do not use matches, candles, open

Failure to comply will result in death or serious injury.
!
WARNING



appliance.
Do not use this boiler if any part has been under

!
7 - GAS SUPPLY PIPING
NOTICE



• Boiler shall be isolated from the gas supply piping

during any pressure testing of gas supply piping

(3.5 kPa).
• Install boiler so that gas ignition system components
are protected from water (dripping, spraying,rain,
etc.) during appliance operation and service
(circulator replacement, condensate trap, control
replacement, etc.).
• Gas meter and supply pipes must be capable of delivering


(19.5 mm) gas supply pipe.
• Support piping with hooks straps, bands, brackets,
hangers, or building structure components to prevent or
dampen excessive vibrations and prevent strain on gas
connection. Boiler will not support piping weight.
• Use thread (joint) compound (pipe dope) suitable for

• 
valve, ground joint union, and sediment trap upstream of
gas controls. See Figure 7-1.
• Install boiler so gas ignition system components are
protected from water dripping, spraying,rain, etc. During
appliance operation and service.
• Leak test boiler and gas line connections before placing
boiler into operation.
7.1 General
• Use piping materials and joining methods acceptable
to authority having jurisdiction. In absence of such

• USA - National Fuel Gas Code, ANSI Z223.1/NFPA 54
• 

• 
supply to meet maximum input at not less than minimum
supply pressure.
• 
from gas supply piping system during any pressure testing
of that system at test pressures in excess of 1/2 psi (3.40
kPa - 34.47 mbar).
