Dunkirk DCBF-125 - Page 43

43
P07
00..02 = No function is associated
03

Note: verify heating mode is enabled (winter or heat only mode)
04

E178 anomaly.
Note: verify heating mode is enabled (winter or heat only mode)
05 = This is an input contact for external DHW recirculation pump. When contact CN2 is closed the pump

To enable input it is necessary to set parameter P04 or P05 = 08 and P69 = 05.
Pump will run at P19 minutes (Summer/Winter mode or Only Winter mode) or P19/2 minutes (only
Summer mode).
00
P09
Manufacturer information
--
P10

00 
01 
02
00
P11..P12
Manufacturer information
--
P13
Max. heating output (0-100%)
100 80
P14
DHW max. output (0-100%)
100
P15
Min. heating output (0-100%)
00
P16
Maximum CH set-point (°C)
00 = 176°F (80°C)
01 = 113°F (45°C)
00
P17
Pump overrun time in heating mode (01-240 minutes)
03
P18
Burner ignition delay in CH mode (00-10 minutes) - 00=10 seconds
03
P19
Manufacturer information
07
P20
Pump overrun time in DHW mode (seconds)
30
P21
Anti-legionellosis function
00 = Disabled -
01 = Enabled
00
P22
Manufacturer information
(set “2242 and above)
00
P23
Maximum DHW set-point temperature 113°-140°F (45°-60°C), Default 49 = 120°F
49
P24
Manufacturer information
35
P25
No water safety device
00
P26..P31
Manufacturer information
--
P32..P41
Diagnostics (See SERVICE Instructions)
--
P44
Temperature unit setting
00 = °C
01 = °F
01
* See Tables : SECTION 12.2 - Parameters Setting For High Altitude.
NOTE : To scroll to parameters 42 and above, it is necessary to set P22 to 22 before scrolling up to the parameter.
P06

00

01
02…05 = no function is associated
00
9.16 Description Of Parameters: Factory Settings conti.
FACTORY SETTINGS
125 150
9 - START UP PROCEDURE
P71* Maximum Fan Speed
Setting 115 220
RPM 6150 7200
P72* Minimum Fan Speed
Setting 40 40
RPM 1150 1150
To calculate fan speeds
(P71 x 10) + 5000
(P72 x 10) + 750
240012564 REV A, [05/15/2019]
