11
4. Part Names
ControlPanel
FeedLever
PowerSwitch
Jogger(left)
FeedBin
MovableGuide
ReferenceGuide
AuxiliaryFeedBin
SlidePlate
Jogger(right)
PaperReceiverStopper
PaperReceiverTray
PowerCord
ConveyanceCover
ConnectorforDownstream
