6. Using the DC-6 mini, DC-8 mini
■Direction at stacking the paper
Depending on the paper size, the stacking direction varies as follows.
6-2. Stacking the Paper
• Stack the paper lengthways as shown in the figure.
If the end of the paper is longer than the tray,
pull out the slide plate so that it does not hang
downwards.
WhenusingpaperbetweenB5andA3
Note:
■Stacking Order of the Paper on the Bin
There are two ways of stacking paper on
the bin.
• Stack the paper sideways as shown in the figure.
WhenusingA5sizepaper
Whenstackingtheprintedsurfaceup
• Put the first page on the top of bin and thereafter stack
the pages in numerical order.
• The paper is discharged to the paper receiver tray with
the printed surface down.
Whenstackingtheprintedsurfacedown
• Put the first page on the bottom bin and thereafter
stack the pages in numerical order.
Select the way more convenient to you.
SlidePlate
Printedsidecannotbeseenas
invertedwithsurfacedown.
Page1
Page2
Page3
Page4
Page5
Page6
Page7
Page8
Printed side can be seen as
invertedwithsurface.
Page8
Page7
Page6
Page5
Page4
Page3
Page2
Page1
