11 | Appendix: Plans and drawings
D-LX 201/721
103
11.3.3 D-LX 201 Ex with housing M4 and S2 for zone 1/21
120
120
148
AF
46
PE 4mm
2
G 1 1/4" (NPT 1 1/4")
G 1/2" (NPT 1/2")
NPT 1/2" (85Ex)
M20x1,5 (84Ex)
99
306
