DURAG D-LX 721 - D-LX 721 with Housing M5;P2

6 | Configuration and function
D-LX 201/721
47
6.2.2 D-LX 721 with housing M5/P2
1
Middle part
2
Seal
3
Screw M4 x 130
8
Cover
10
Cable gland for connecting cable
11
Fibre-optic cable adapter
12
(optional) for /MP3 plug connector device variants
13
Plug-in cover
14
Screw M3 x 10
Fig.6.5: Exploded view (figure shows housing P2)
