2.3 Tilting the machine head up
For maintenance work the machine head can be tilted up.
For this purpose the transport carriage must be in its rear position.
Caution: Danger of injury!
Switchthemainswitchoff.
Tilt the machine head up only with the main switch turned off.
Tilting the machine head up
–
Remove the covering hood 1.
For this purpose lift the covering hood at the front so that the
locking is released. Lift the covering hood off carefully.
–
Swing the folding station 2 out by 90°.
–
Swivel the locking lever 4 up.
–
Lift the fabric sliding sheet 3 at the front and swivel it to the left.
–
Lift the machine head in the area of the head cover and tilt it up
carefully until catch 5 locks. The latch snaps in additionally.
The space under the machine table is accessible for cleaning work.
Sw inging the machine head back
–
Lift catch 5.
–
Swing the machine head back carefully.
Caution: Danger of injury!
Hold the machine head tight until it is completely at rest when lowered.
Danger of squashing your fingers between machine head and table
top.
–
Insert the fabric sliding sheet.
–
Swivel the locking lever 4 down.
–
Tilt the folding station 2 back and insert it.
–
Put the covering hood 1 on again.
