DURKOPP ADLER 745-34 Speedpocket Operating Instructions

2.5 Threading in the needle thread
Caution: Danger of injury!
Switchthemainswitchoff.
Thread needle threads in only with the sewing unit s witched off.
The threading-in of the needle threads is done in ascending numerical
order, as shown in the illustrations opposite:
–
Swing the folding station aside
Left needle
–
Put the thread reel on the thread reel holder.
–
Thread the thread from the thread reel through the drill-hole 1 of
the thread reel holder.
–
Guide the thread through the guide 2.
–
Guide the thread through the drill-hole in s upport plate 3.
–
Guide the thread through the guide 5.
–
Guide the thread through the tensions discs of needle thread
tension 6.
–
Guide the thread through the thread controller spring 8.
–
Guide the thread through the drill-hole in s upport plate 10.
–
Thread the thread through the drill-hole in thread lever 17.
–
Guide the thread downward through the thread puller 16.
–
Thread the thread through the guide 15, through the needle thread
monitor 14 and through the thread guide 13 (not visible).
–
Thread the thread through the guide 12 (not visible), through the
drill-hole in the needle holder and through the eye of the needle.
Right needle
–
Put the thread reel on the thread reel holder
–
Thread the thread from the thread reel through the drill-hole 1 of
the thread reel holder.
–
Guide the thread through the guide 2.
–
Guide the thread through the drill-hole in the support plate 3.
–
Thread the thread through the tension disc of the needle thread
tension 4.
–
Thread the thread through the guides 5 and 7.
–
Guide the thread through the thread controller spring 9.
–
Guide the thread through the drill-hole in s upport plate 10.
–
Thread the thread through the drill-hole in the thread lever 17.
–
Thread the thread downward through the thread puller 16, through
the guide 15, through the needle thread monitor 11 and through the
thread guide 13.
–
Thread the thread through the guide 12 (not visible), through the
drill-hole in the needle holder and through the eye of the needle.
–
Clamp the threads in the needle thread catcher and cut them off.
