2.14.2 Sewing with flap
For the simultaneous sewing-in of flaps o r other additional parts the
following optional equipment is required according to the field o f
application:
Production of trousers: Right flap clamp (Order No. 0792 011162)
Or Left flap clamp (Order No. 0792 011161)
2.14.2.1 Sewing without light-barrier
Form stop for the flap
The unmachined part 1 is delivered with the flap clamp 2.
It has to be machined as a form stop corresponding to the flap used.
ATTENTION!
The flap length must correspond to the desired length of the pocket
opening.
1
33
21
