2.14.2.2 Sewing with light-barrier
When attaching flaps, seam beginning and seam end are recognized
by a light-barrier.
Positioning the flap
The positioning marks 1 and 2 on the folder limit the sewing area for
the attaching of flaps.
–
Always position the flaps within the marked area.
If the flap is not positioned correctly, the error message
Err 9721 or Err 9722 appears.
Correction of seam beginning and seam end
The correction of the seam beginning (NA) and seam end (NE) when
sewing with light-barrier is done in the pocket correction program (see
Programming Instructions).
35
1
21
