2.10.1 Swinging the corner knife station out / in
Caution: Danger of injury!
Switchthemainswitchoff.
Swing the corner knife station out only with the sewing unit switched
off.
Sw inging the corner knife station out
–
Swing the corner knife station 1 out to the left.
The knives are accessible for adjusting and service work.
Sw inging the corner knife station in
–
Swing the corner knife station 1 back under the sewing unit and let
it catch.
ATTENTION!
The corner knife station must audibly lock when being pushed in.
Hint:
If the corner knife station is swung out with the sewing unit switched
on, the following message appears:
Err 9001
24
