Positioning the piping strip
Double piping:
–
Position the piping strip centered on the feeding clamps and flush
at the front edges.
Left single piping w ith separately positioned right facing:
–
Position the piping strip on the left feeding clamp flush with the
cutting line.
–
Position the facing on the right feeding clamp.
This positioning method requires the flap clamp “right” (Order
No.0792 011162) available as optional equipment.
–
The edges 1 and 2 have to b e sufficiently caught by the needle, but
must not be cut by the center knife.
Left single piping w ith grow n-on facing
–
Positionthepipingstripatthestopguide3ontheleftfolding
sheet.
ATTENTION!
In case of grown-on facings the right folding sheet
must not close.
Pull off the hose coupling from the right feeding clamp
.
32
3
12
