Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
27
Operation, Parts, and Instruction Manual
Figure 33 Model 361 Piston Ring Detail
Key 48 - Multiple
Graphite Piston Ring
26
5
19
3
15
12
1
20
21
19
26
22
1
Key 48 - Single
Graphite Piston Ring
