Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
49
Operation, Parts, and Instruction Manual
Table 24
Cage (Key 19) - 361 Equal Percentage - Double Piston Ring
Valve Size Inch Port Size Cage Material
Globe Body Inch (mm) S17400 H900 S17400 DH1150 S31600 / ENC
1, 1-1/2x1, 2x1 1-5/16 (33.3) 2U21533327D 2U21531150D 2U74084893D
1-1/2 1-7/8 (47.6) 2U21953327D 2U21951150D 2U74094893D
2, 3x2 2-5/16 (58.7) 2U22373327D 2U22371150D 2U74104893D
3 3-7/16 (87.3) 2U23213327D 2U23211150D 2U74124893D
4 4-3/8 (111.1) 2U23633327D 2U23631150D 2U74134893D
4x2-1/2 2-7/8 (73.0) 2U22793327D 2U22791150D 2U74114893D
6 7 (177.8) 2U50593327D 2U50591150D 2U80674893D
6x4 4-3/8 (111.1) 2V37233327D 2V37231150D 2V37134893D
8
2 Inch Travel
8 (203.2) 20A3245X01D 20A3245X05D 20A5467X01D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
Table 25
Cage (Key 19) - 361 Linear - Double Piston Ring
Valve Size Inch Port Size Cage Material
Globe Body Inch (mm) S17400 H900 S17400 DH1150 S31600 / ENC
1, 1-1/2x1, 2x1 1-5/16 (33.3) 2U21563327D 2U21561150D 2U74144893D
1-1/2 1-7/8 (47.6) 2U21983327D 2U21983150D 2U74154893D
2, 3x2 2-5/16 (58.7) 2U22403327D 2U22401150D 2U74164893D
3 3-7/16 (87.3) 2U23243327D 2U23241150D 2U74184893D
4 4-3/8 (111.1) 2U23663327D 2U23661150D 2U74194893D
4x2-1/2 2-7/8 (73.0) 2U22823327D 2U22821150D 2U74174893D
6 7 (177.8) 2U50613327D 2U50611150D 2U80684893D
6x4 4-3/8 (111.1) 2V37183327D 2V37181150D 2V37124893D
8
2 Inch Travel
8 (203.2) 20A3247X01D 20A3247X05D 20A5468X01D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
