Model 360/361 Control Valves
P-360M1019A
48
Operation, Parts, and Instruction Manual
Table 21
Cage (Key 19) - 360 Equal Percentage
Valve Size Inch Port Size Cage Material
Globe Body Angle Body Inch (mm) S17400 H900 S17400 DH1150 S31600 / ENC
1, 1-1/2x1, 2x1 1, 2x1 1-5/16 (33.3) 2U21533327D 2U21531150D 2U74084893D
1-1/2 2, 3x1-1/2 1-7/8 (47.6) 2U21953327D 2U21951150D 2U74094893D
2, 3x2 4x2 2-5/16 (58.7) 2U22373327D 2U22371150D 2U74104893D
- 3 2-7/8 (73.0) 2U22793327D 2U22791150D 2U74114893D
3 4 3-7/16 (87.3) 2U23213327D 2U23211150D 2U74124893D
4 6 4-3/8 (111.1) 2U23633327D 2U23631150D 2U74134893D
4x2-1/2 - 2-7/8 (73.0) 2U22793327D 2U22791150D 2U74114893D
6 - 7 (177.8) 2U50593327D 2U50591150D 2U80674893D
6x4 - 4-3/8 (111.1) 2V37233327D 2V37231150D 2V37134893D
8 - 8 (203.2) 20A3245X01D 20A3245X05D 20A5467X01D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
Table 22
Cage (Key 19) - 360 Anti-Cavitation (S17400 H900 Cage Material)
Valve Size
Inch
Port Size
Inch (mm)
Stage
Stage 1
1 1 (25.4) 38A1018X01D
1-1/2 1-5/16 (33.3) 38A1019X01D
2 1-7/8 (47.6) 38A1020X01D
3 2-7/8 (73.0) 38A1023X01D
4 4-3/8 (111.1) 38A1025X01D
4 x 2-1/2
(1)
2-7/8 (73.0) 38A1021X01D
6 7 (177.8) 38A1027X01D
8 8 (203.2) 360C8000X1D
1 - Indicates Reduced Trim
Table 23
Cage (Key 19) - 360 Anti-Cavitation (S17400 H900 Cage Material)
Valve Size
Inch
Port Size
Inch (mm)
Stage
Stage 2
1 1 (25.4) 24A5558X01D
1-1/2 1-5/16 (33.3) 24A5559X02D
2 1-7/8 (47.6) 24A3031X03D
3 2-7/8 (73.0) 23A9453X02D
4 2-7/8 (73.0) 23A5817X03D
4 x 2-1/2
(1)
2-5/16 (58.7) 360C4009X1D
6 5-3/8 (136.5) 360C6011X1D
8 7 (177.8) 360C8004X1D
1 - Indicates Reduced Trim
