Operation, Parts, and Instruction Manual
Table 19
Cage (Key 19) - 360 Quick Opening
Valve Size Inch Port Size Cage Material
Globe Body Angle Body Inch (mm) S17400 H900 S17400 DH1150 S31600 / ENC
1, 1-1/2x1, 2x1 1, 2x1 1-5/16 (33.3) 2U21503327D 2U21501150D 2U74034893D
1-1/2 2, 3x1-1/2 1-7/8 (47.6) 2U21923327D 2U21921150D 2U72544893D
2, 3x2 4x2 2-5/16 (58.7) 2U22343327D 2U22341150D 2U74044893D
- 3 2-7/8 (73.0) 2U22763327D 2U22761150D 2U74054893D
3 4 3-7/16 (87.3) 2U23183327D 2U23181150D 2U74064893D
4 6 4-3/8 (111.1) 2U23603327D 2U23601150D 2U74074893D
4x2-1/2 - 2-7/8 (73.0) 2U22763327D 2U22761150D 2U74054893D
6 - 7 (177.8) 2U50633327D 2U50631150D 2U80694893D
6x4 - 4-3/8 (111.1) 2V37223327D 2V37221150D 2V37194617D
8 - 8 (203.2) 20A3249X01D 20A3249X02D 20A5469X01D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
Table 20
Cage (Key 19) - 360 Linear
Valve Size Inch Port Size Cage Material
Globe Body Angle Body Inch (mm) S17400 H900 S17400 DH1150 S31600 / ENC
1, 1-1/2x1, 2x1 1, 2x1 1-5/16 (33.3) 2U21563327D 2U21561150D 2U74144893D
1-1/2 2, 3x1-1/2 1-7/8 (47.6) 2U21983327D 2U21983150D 2U74154893D
2, 3x2 4x2 2-5/16 (58.7) 2U22403327D 2U22401150D 2U74164893D
- 3 2-7/8 (73.0) 2U22823327D 2U22821150D 2U74174893D
3 4 3-7/16 (87.3) 2U23243327D 2U23241150D 2U74184893D
4 6 4-3/8 (111.1) 2U23663327D 2U23661150D 2U74194893D
4x2-1/2 - 2-7/8 (73.0) 2U22823327D 2U22821150D 2U74174893D
6 - 7 (177.8) 2U50613327D 2U50611150D 2U80684893D
6x4 - 4-3/8 (111.1) 2V37183327D 2V37181150D 2V37124893D
8 - 8 (203.2) 20A3247X01D 20A3247X05D 20A5468X01D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
