Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
33
Operation, Parts, and Instruction Manual
Parts
Key Description Part Number
1 Body
If you need a body as a replacement part, order by
valve size and stem diameter, serial number and desired
material.
2 Stud, Bonnet/Body
NOTE: Anti-Cavitation 2 Stage and Low-Noise III D3
Trim may require a bonnet spacer and will require
special studs. Consult Dyna-Flo.
Refer to Table 5 for Angle Body stud size equivalents.
-B7
1 inch (4 Required) 1R2848X057D
1-1/2 inch (8 Required) 1K2429X056D
2 inch (8 Required) 1K2429X056D
3 inch (8 Required) 1A3781X045D
4 inch (8 Required) 1R3690X042D
6 inch (12 Required) 1A36563101D
8 inch (16 Required) 1D94523101D
-B8M
1 inch (4 Required) 1R28483522D
1-1/2 inch (8 Required) 1K24293522D
2 inch (8 Required) 1K24293522D
3 inch (8 Required) 1A3781CL28D
4 inch (8 Required) 1R3690CL28D
6 inch (12 Required) 1A36563522D
8 inch (16 Required) 1D9452CL28D
-B7M
1 inch (4 Required) 1R2848B7MDD
1-1/2 inch (8 Required) 1K2429B7MDD
2 inch (8 Required) 1K2429B7MDD
3 inch (8 Required) 1A3781B7MDD
4 inch (8 Required) 1R3690B7MDD
6 inch (12 Required) 1A3656B7MDD
8 inch (16 Required) 1D9452X011D
-B7 Fluorokote #1
1 inch (4 Required) 1R2848XFK1D
1-1/2 inch (8 Required) 1K2429XFK1D
2 inch (8 Required) 1K2429XFK1D
3 inch (8 Required) 1A3781XFK1D
4 inch (8 Required) 1R3690XFK1D
6 inch (12 Required) 1A3656XFK1D
8 inch (16 Required) 1D9452XFK1D
-B7M Fluorokote #1
Key Description Part Number
1 inch (4 Required) 1R2848XFK3D
1-1/2 inch (8 Required) 1K2429XFK3D
2 inch (8 Required) 1K2429XFK3D
3 inch (8 Required) 1A3781XFK3D
4 inch (8 Required) 1R3690XFK3D
6 inch (12 Required) 1A3656XFK3D
8 inch (16 Required) 1D9452XFK3D
3 Valve Plug
Refer to Tables 8 - 18
4 Pin, S31600
3/8 inch (9.5 mm) Stem 1V32263507D
1/2
inch (12.7mm) Stem 1V32273507D
3/4
inch (19.1mm) Stem 1V32603507D
1 inch (25.4 mm) Stem 1V3340NT05D
5 Valve Stem
Refer to Tables 8 - 18
6 Backup Ring, Two-Piece Plug Seal,
-Fluoroelastomer (Viton)
1-5/16 inch port diameter 1V65900529D
1-7/8 inch port diameter 1V65920529D
2-5/16 inch port diameter 1V55070529D
2-7/8 inch port diameter 1V65940529D
3-7/16 inch port diameter 1V65960529D
4-3/8 inch port diameter 1V65980529D
7 inch port diameter 1V66000529D
-Nitrile
1-5/16 inch port diameter 1V65900305D
1-7/8 inch port diameter 1V65920305D
2-5/16 inch port diameter 1V55070305D
2-7/8 inch port diameter 1V65940305D
3-7/16 inch port diameter 1V65960305D
4-3/8 inch port diameter 1V65980305D
7 inch port diameter 1V66000305D
-Ethylene Propylene
1-5/16 inch port diameter 1V6590X004D
1-7/8 inch port diameter 1V6592X003D
2-5/16 inch port diameter 1V5507X004D
2-7/8 inch port diameter 1V6594X003D
3-7/16 inch port diameter 1V6596X003D
4-3/8 inch port diameter 1V6598X002D
7 inch port diameter 1V6600X002D
7 Seal Ring, Two-Piece Plug Seal,
-Carbon-fi lled PTFE (Standard)
1-5/16 inch port diameter 1V65910509D
1-7/8 inch port diameter 1V65930509D
