Model 360/361 Control Valves
P-360M1019A
34
Operation, Parts, and Instruction Manual
Parts (Continued)
Key Description Part Number
7 Seal Ring, Two-Piece Plug Seal (Continued)
-
Carbon-fi lled PTFE (Standard)
2-5/16 inch port diameter 1V55080509D
2-7/8 inch port diameter 1V65950509D
3-7/16 inch port diameter 1V65970509D
4-3/8 inch port diameter 1V65990509D
7 inch port diameter 1V66010509D
8
Seal Ring, Three-Piece Plug Seal, Carbon-fi lled PTFE/
Elgiloy
1-5/16 inch port diameter 10A4207X03D
1-7/8 inch port diameter 10A4216X03D
2-5/16 inch port diameter 10A4206X03D
2-7/8 inch port diameter 10A4215X03D
3-7/16 inch port diameter 10A5351X06D
4-3/8 inch port diameter 10A4223X03D
7 inch port diameter 10A2643X03D
8 inch port diameter 10A3261X03D
9 Backup Ring, Three-Piece Plug Seal,
S31600/S31603 Dual Grade
1-5/16 inch port diameter 10A4209X02D
1-7/8 inch port diameter 10A4218X01D
2-5/16 inch port diameter 10A4208X02D
2-7/8 inch port diameter 10A4217X02D
3-7/16 inch port diameter 10A5349X02D
4-3/8 inch port diameter 10A4224X02D
10 Retaining Ring, Three-Piece Plug Seal, S31600
1-5/16 inch port diameter 10A4211X01D
1-7/8 inch port diameter 10A4220X01D
2-5/16 inch port diameter 10A4210X01D
2-7/8 inch port diameter 10A4219X01D
3-7/16 inch port diameter 10A5350X01D
4-3/8 inch port diameter 10A4225X01D
11 Anti-Extrusion Ring, Three-Piece Plug Seal,
PolyEtherEtherKetone (PEEK)
1-5/16 inch port diameter 23B6125X01D
1-7/8 inch port diameter 22B4694X01D
2-5/16 inch port diameter 21B9340X01D
2-7/8 inch port diameter 22B2617X01D
3-7/16 inch port diameter 23B6126X01D
4-3/8 inch port diameter 21B9341X01D
7 inch port diameter 22B5998X01D
Key Description Part Number
12 Gasket, Seat Ring, S31600/Graphite
1 inch 1R2862X011D
1-1/2 inch 1R3098X005D
2 inch 1R3296X004D
3 inch 1R3481X005D
4 inch 1J5047X006D
6 inch 1U5086X003D
8 inch 10A3266X08D
13 Seat Ring Adapter, Reduced Trim,
S31600/S31603 Dual Grade Refer to Table 27
14 Gasket, Seat Ring Adapter, S31600/Graphite
2 x 1 inch 1R2862X011D
3 x 2 inch 1R3296X004D
15 Seat Ring
Refer to Tables 28 - 29
15A Liner, Angle Body Valves Contact Dyna-Flo
16 Disk Seat, Soft Seat Valves,
S31600/S31603 Dual Grade Refer to Table 30
17 PTFE Disk, Soft Seat Valves,
PTFE Refer to Table 30
18 Disk Retainer, Soft Seat Valves,
S31600/S31603 Dual Grade Refer to Table 30
19 Cage
Refer to Tables 18 - 26
20 Spiral Wound Gasket
- S30400/Graphite
1 inch 1R2860X006D
1-1/2 inch 1R30999928D
2 inch 1R32979928D
3 inch 1R34829928D
4 inch 1R37229928D
6 inch 1U50859928D
-N06600/Graphite
1-1/2 x 1 inch 1R28609944D
2 x 1 inch 1R28609944D
6 x 4 inch 1U50859944D
21 Metal Shim, S30400
1 inch 16A1936X01D
1-1/2 inch 16A1937X01D
2 inch 16A1938X01D
3 inch 16A1940X01D
4 inch 16A1941X01D
6 inch 16A1942X01D
