Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
35
Operation, Parts, and Instruction Manual
Parts (Continued)
Key Description Part Number
22 Gasket, Body/Bonnet, S31600/Graphite
1 inch 1R2859X004D
1-1/2 inch 1R3101X003D
1-1/2 x 1 inch 1R2861X004D
2 inch 1R3299X004D
2 x 1 inch 1R2861X004D
3 inch 1R3484X004D
3 x 2 inch 1R3298X003D
4 inch 1R3724X004D
6 inch 1U5081X005D
8 inch 10A3265X11D
23 Load Ring, 8 inch valve only,
S17400 20A3267X01D
24 Cage Adapter, Reduced Trim,
S31600/S31603 Dual Grade Refer to Table 27
25 Bonnet Gasket for Cage Adapter, S31600/Graphite
1-1/2 x 1 inch 1R3101X003D
2 x 1 inch 1R3299X004D
3 x 2 inch 1R3484X004D
26 Bonnet
If you need a bonnet as a replacement part, order by
valve size and stem diameter, serial number and desired
material.
26A Bonnet Spacer
If you need a bonnet spacer as a replacement part,
order by valve size and stem diameter, characteristic,
serial number and desired material.
27 Baffl e, included as part of extension bonnet assembly
28 Nut, Body/Bonnet
-2H
1 inch (4 Required) 1C33062407D
1-1/2 inch (8 Required) 1A3772X066D
2 inch (8 Required) 1A3772X066D
3 inch (8 Required) 1A3760X059D
4 inch (8 Required) 1A3520X060D
6 inch (12 Required) 1A44092407D
8 inch (16 Required) 1A44522407D
-2HM
1 inch (4 Required) 1C33062HMDD
1-1/2 inch (8 Required) 1A37722HMDD
2 inch (8 Required) 1A37722HMDD
3 inch (8 Required) 1A37602HMDD
Key Description Part Number
4 inch (8 Required) 1A35202HMDD
6 inch (12 Required) 1A44092HMDD
8 inch (16 Required) 1A44522HMDD
-8M
1 inch (4 Required) 1C33063525D
1-1/2 inch (8 Required) 1A3772X023D
2 inch (8 Required) 1A3772X023D
3 inch (8 Required) 1A37603525D
4 inch (8 Required) 1A35203525D
6 inch (12 Required) 1A44093525D
8 inch (16 Required) 1A44523525D
-2H Fluorokote #1
1 inch (4 Required) 1C3306XFK1D
1-1/2 inch (8 Required) 1A3772XFK1D
2 inch (8 Required) 1A3772XFK1D
3 inch (8 Required) 1A3760XFK1D
4 inch (8 Required) 1A3520XFK1D
6 inch (12 Required) 1A4409XFK1D
8 inch (16 Required) 1A4452XFK1D
-2HM Fluorokote #1
1 inch (4 Required) 1C3306XFK3D
1-1/2 inch (8 Required) 1A3772XFK3D
2 inch (8 Required) 1A3772XFK3D
3 inch (8 Required) 1A3760XFK3D
4 inch (8 Required) 1A3520XFK3D
6 inch (12 Required) 1A4409XFK3D
8 inch (16 Required) 1A4452XFK3D
29 Stud, Packing, B8M, 2 Required
3/8 inch (9.5 mm) Stem 1E94413522D
1/2
inch (12.7mm) Stem 1E94443525D
3/4
inch (19.1mm) Stem 1E94493525D
1 inch (25.4 mm) Stem 0V00253522D
30 Lower Wiper, Tefl on
3/8 inch (9.5 mm) Stem 1J87210699D
1/2
inch (12.7mm) Stem 1E94443522D
3/4
inch (19.1mm) Stem 1E94493522D
1 inch (25.4 mm) Stem 1J87240699D
31 Packing Box Ring, S31600/S31603 Dual Grade
3/8 inch (9.5 mm) Stem 1J87313507D
1/2
inch (12.7mm) Stem 1J87323507D
3/4
inch (19.1mm) Stem 1J87333507D
1 inch (25.4 mm) Stem 1J87343507D
32 Spring, Packing, SST Refer to Table 32
