Model 360/361 Control Valves
P-360M1019A
36
Operation, Parts, and Instruction Manual
Parts (Continued)
Key Description Part Number
33 Special Washer, SST Refer to Table 32
34 Packing Set, PTFE Refer to Table 32
35 Packing Follower, S31600/S31603 Dual Grade
3/8 inch (9.5 mm) Stem 1E94393507D
1/2
inch (12.7mm) Stem 1E94433507D
3/4
inch (19.1mm) Stem 1E94473507D
1 inch (25.4 mm) Stem 1H98233507D
36 Upper Wiper, Felt
3/8 inch (9.5 mm) Stem 1J87260633D
1/2
inch (12.7mm) Stem 1J87270633D
3/4
inch (19.1mm) Stem 1J87280633D
1 inch (25.4 mm) Stem 1J87290633D
37 Packing Flange
-Carbon Steel - Plated
3/8 inch (9.5 mm) Stem 1E94372410D
1/2
inch (12.7mm) Stem 1E94422307D
3/4
inch (19.1mm) Stem 1E94482307D
1 inch (25.4 mm) Stem 0V00242505D
-S31600/S31603 Dual Grade
3/8 inch (9.5 mm) Stem 1E94373507D
1/2
inch (12.7mm) Stem 12B6924X01D
3/4
inch (19.1mm) Stem 12B6925X01D
1 inch (25.4 mm) Stem 0V00243507D
38 Nut, Packing, 8M, 2 Required
3/8 inch (9.5 mm) Stem 1E94403525D
1/2
inch (12.7mm) Stem 1E94453525D
3/4
inch (19.1mm) Stem 1E94463525D
1 inch (25.4 mm) Stem 1A34333525D
39 Lantern Ring, Refer to Table 32
S31600/S31603 Dual Grade
40 Graphite Filament, Refer to Table 32
41 Graphite Ribbon, Refer to Table 32
42 Jam Nut, Valve Stem, Steel/Zinc Plated
3/8 inch (9.5 mm) Stem NHJFZ38
1/2
inch (12.7mm) Stem NHJFZ12
3/4
inch (19.1mm) Stem NHJFZ34
1 inch (25.4 mm) Stem NHJFZ100
43 Hex Nut, Valve Stem, Steel/Zinc Plated
3/8 inch (9.5 mm) Stem NHFZ38
1/2
inch (12.7mm) Stem NHFZ12
3/4
inch (19.1mm) Stem NHFZ34
1 inch (25.4 mm) Stem NH8FZ100
Key Description Part Number
44 Yoke Locknut, Steel Plated
2-1/8 inch (54 mm) Yoke Boss 1E79302306D
2-13/16 inch (71 mm) Yoke Boss 1E80742306D
3-9/16 inch (127 mm) Yoke Boss 1E83272306D
45 Flow Arrow, S30400
1 inch 1V10593898D
1-1/2” - 8” 1V10603898D
46 Name Tag, S30400 NAMEXSBODYD
47 Name Plate, S30400 Refer to Actuator
48 Piston Ring, Graphite Refer to Table 34
49 Cage Retainer Contact Dyna-Flo
Low-Noise III A3, B3, C3 Trim
50 Baffl e Contact Dyna-Flo
Low-Noise III A3, B3, C3 Trim
49/50 Cage Retainer/Baffl e Assembly Contact Dyna-Flo
Low-Noise III D3
Parts (Live Loaded Packing)
Key Description Part Number
901 Live Loaded Packing Flange,
Refer to the P-LLPS Manual
902 O-Ring,
Refer to the P-LLPS Manual
903 Spring Washers,
Refer to the P-LLPS Manual
904 Live Loaded Packing Follower,
Refer to the P-LLPS Manual
905 Live Loaded Packing Box Ring,
Refer to the P-LLPS Manual
906 Live Loaded Lower Wiper,
Refer to the P-LLPS Manual
907 Live Loaded V-Ring Packing Set,
Refer to the P-LLPS Manual
911 Anti-Extrusion Ring,
Refer to the P-LLPS Manual
914 Live Loaded Lantern Ring,
Refer to the P-LLPS Manual
